Specifications

• DN 25 – 1″ 2 way Brass Ball Valve
• The SC2C2A9 is a full bore ball valve with a Male end and a Female end
• Flow Rate: 43 Kvs
• Features a Brass CW617N Body (Nickel Plated) and Ball (Chromed Nickel)
• Sleeve and Ball Seal: PTFE
• O-Rings: EPDM
• Fluid Temperatures: +5°C – +100°C
• Also available is a version of this valve for use in Thermal Solar systems which has a maximum fluid temperature of +160°C
• As standard, the SC2C2A9 is compatible with Sintesi actuators for example the RFSR2221BQ or the RFSS2221BQ Domestic Hot Water (DHW) series
