Specifications

• Pressure; 0 – 9 Bar
• Media: Steam
• Media Temperature: – 10°C ÷ + 180°C
• Ambient Temperature: – 10°C ÷ + 70°C
• Orifice size: Ø1.0mm
• Flow rate Kv (m³/h): 0.03
• Body material: Brass
• Operator material: AISI 430F Stainless Steel
• Seal material: Sigodur (Filled PTFE)
• Sigodur (Filled PTFE) seals are suitable for heavy duty applications
• A range of Orifice sizes and flow rates are available on request

Choose Voltage…71Z1 – 12v (DC) – £122.467201 – 24v (AC) – £120.6472Z1 – 24v (DC) – £120.647401 – 110v (AC) – £120.647701 – 230v (AC) – £120.64

Add to Cart

Prices shown do not include VAT
*VAT will be added at cart and checkout
