Additional information
| Action | Direct Acting |
|---|---|
| Function | 2 Way |
| Operation | Normally Closed |
| Application | |
| Size | |
| Zero Bar Rated | Yes |
| Valve Material | Brass |
D263DVA 1/4″ FKM 2/2 NC Max 30 Bar
Sale!
From £58.35
D263DVA
Specifications
- Pressure; 0 – 30 Bar
- Media: Oil, Air, Water
- Media Temperature: – 10°C ÷ + 130°C
- Ambient Temperature: – 10°C ÷ + 50°C
- Orifice size: Ø1.0mm
- Flow rate Kv (m³/h): 0.03
- Body material: Brass
- Operator material: AISI 430F Stainless Steel
- Seal material: FKM
- A range of Orifice sizes and flow rates are available on request
Prices shown do not include VAT
*VAT will be added at cart and checkout
This product is part of the 50% online only discount on select Solenoid Valves
Coil Voltage
Select Required Voltage
230V AC 50/60Hz coil (7700) and DIN connector
£34.77
110V AC 50/60Hz coil (7400) and DIN connector
£34.77
24V AC 50/60Hz coil (7200) and DIN connector
£34.77
24V DC coil (7250) and DIN connector
£34.77
12V DC coil (7150) and DIN connector
£36.61
Without coil (valve body only)
