1″ – 3 Way Brass Ball Valve [M/M/M] SC3C3A
£92.50
SC3C3A
Specifications
- DN 25 – 1″ 3 way Brass Ball Valve
- The SC3C3A is a full bore 3 hole ball valve with Male ends
- Flow Rate: 18.5 Kvs
- Features a Brass CW617N Body (Nickel Plated) and Ball (Chromed Nickel)
- Sleeve and Ball Seal: PTFE
- O-Rings: EPDM
- Fluid Temperatures: +5°C – +100°C
- Also available is a version of this valve for use in Thermal Solar systems which has a maximum fluid temperature of +160°C
- As standard, the SC3C3A is compatible with Sintesi actuators for example the RFSR2221BQ or the RFSS2221BQ Domestic Hot Water (DHW) series
Prices shown do not include VAT
*VAT will be added at cart and checkout
